2010 Ducati Hypermotard 1100 EVO SP is a vehicle created for the extreme rider. Ducati Hypermotard 1100 SP EVO has a 1078cc engine capacity, L-Twin cylinder, 2 valve per cylinder desmodromic, water cooled. In addition EVO Ducati Hypermotard 1100 S has a different type from the same species, this vehicle has a quality and a higher specification. Since this has been made with a plan. Ducati as the author has been predicted that someday there will be a different driver than the others, who likes a new challenge, a very extreme case. To this end ducati modify or repair a vehicle before a vehicle to become stronger, faster, filled with extreme and ditomapng capabilities with a sophisticated technology that is more convenient for motorists and easy to ride. To view detailed information about the specifications and technology used you can see or read below.
2010 Ducati Hypermotard 1100 EVO SP Motorcycle
2010 Ducati Hypermotard 1100 EVO SP Motorcycle
2010 Ducati Hypermotard 1100 EVO SP Motorcycle
2010 Ducati Hypermotard 1100 EVO SP Motorcycle
2010 Ducati Hypermotard 1100 EVO SP Motorcycle2010 Ducati Hypermotard 1100 EVO SP - Specifications
Engine
Type L-Twin cylinder, 2 valve per cylinder Desmodromic, air cooled
Displacement 1078cc
Bore x Stroke 98x71.5mm
Compression Ratio 11.3:1
Power 95hp (69.9kW) @ 7500rpm
Torque 75.9lb-ft 10.5kgm @ 5750rpm
Fuel injection
Siemens electronic fuel injection, 45mm throttle body
Exhaust
Lightweight 2-1-2 system with catalytic converter with twin lambda probes
Transmission
Gearbox 6 speed
Ratio 1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=24/28
Primary Drive Straight cut gears, Ratio 1.84:1
Final Drive Chain, Front sprocket 15, Rear sprocket 41
Clutch Dry multiplate with hydraulic control
Emissions
Standard Euro 3
Chassis
Frame Tubular steel Trellis frame
Wheelbase 1465mm (57.7in)
Rake 24°
Front Suspension Marzocchi 50mm fully adjustable usd forks with DLC
Front Wheel Travel 195mm (7.7in)
Front Wheel 5-spoke in forged light alloy 3.50x17
Front Tyre 120/70 ZR17
Rear Suspension Progressive linkage with fully adjustable Öhlins monoshock. Aluminium single-sided swingarm
Rear Wheel Travel 156mm (6.1in)
Rear Wheel 5-spoke forged light alloy 5.50x17
Rear Tyre 180/55 ZR17
Front Brake 2 x 305mm semi-floating discs, radially mounted Brembo Monobloc callipers 4-piston, 2-pad
Rear Brake 245mm disc, 2-piston calliper
Fuel Tank Capacity 12.4l - 3.3gallon (US)
Dry Weight 171kg (377lb)
Instruments
Digital unit with displays for: Speedometer, rev counter, lap times, time, oil temp, battery voltage, A & B trips, fuel reserve trip, scheduled maintenance. Warning lights for: Neutral, turn signals, high-beam, rev-limit, oil pressure, fuel reserve. Plus: Immobilizer system and management of DDA system
Warranty 2 years unlimited mileage
Body Colour (Frame/Wheel) Corse red (red / black) - Corse white (red / black)
Versions Dual seat
Seat Height875mm (34.5in)
DDA
Standard equipment
DTC
Not available on this model
ABS
Not available on this model
Features on 2010 Ducati Hypermotard 1100 EVO SP Motorcycle
- SP lightweight wheels by Marchesini
Extreme riders know that one of the best ways to improve the handling and performance of a motorcycle is to reduce its unsprung weight by upgrading to superior lightweight wheels. Even from a distance, the 5-spoke black Marchesini wheels with red pin-striping confirm the high performance of the Hypermotard 1100EVO SP. Created from forged then machined alloy, both front and rear wheels are significantly lighter and create a lower moment of inertia and unsprung weight, resulting in improved acceleration and braking as well as quicker steering. Mounted to the lightweight wheels are Z-rated Pirelli Diablo Supercorsa SP tyres. Designed to deliver racing performance on the road, they give great feedback, are stable under severe braking and feature a sure-footed 'feel' when braking or accelerating is applied at considerable lean angles.
- SP suspension
Brand new longer, black-bodied, fully adjustable 50mm Marzocchi forks have 30mm (1.2in) more travel and increase the SP's ground clearance by 30mm (1.38in), extending the SP's extreme cornering performance and providing a more track-oriented set-up. Coated with a durable low friction, DLC (diamond-like carbon) black coating, the sliders enable the Hypermotard 'SP' to respond effortlessly to every minute variation in the tarmac, improving on its already impressive road holding. The advanced 'SP' suspension is further enhanced with an Öhlins remote reservoir rear shock, renowned in racing as the ultimate performance choice. This incredible shock is fully adjustable for compression and rebound damping as well as spring pre-load, ensuring that the 'SP' is readily adaptable to every riding style and road or track it challenges.
- SP colours
The Hypermotard 1100EVO SP is boldly finished in a choice of red-themed or white-themed Ducati Corse livery to underline its competition intention.
The white-themed livery has a white tank with thin red stripe and red Ducati graphic, contrasted with a black knee-panel area. The headlight fairing and beak section are also white with a wide red stripe along the centre of the beak and thin black striping around the fairing section. The tailpiece is white with a wide red stripe along its centre.
The red-themed livery has a red tank with thin white stripe and white Ducati graphic, contrasted with a black knee-panel area. The headlight fairing and beak section are also red with a wide white stripe along the centre of the beak and thin white striping around the fairing section. The tailpiece is red with a wide white stripe along its centre.
Both colour schemes have red Trellis frames with black wheels and the new Ducati Corse logo proudly displayed on the Hypermotard's beak section.
- SP brakes
With a bike as extreme as the Hypermotard 1100EVO SP, superior stopping power is fundamental, so world-class braking performance is assured by using the same Brembo Monobloc callipers as on Ducati's top Superbikes. Machined from a single piece of alloy, the callipers achieve a higher rigidity and resistance to distortion during extreme braking, which not only delivers incredible braking power, but also provides an enhanced and precise 'feel' at the brake lever. The twin Monobloc callipers, each with four 34mm pistons gripping 305mm discs, guarantee spectacular braking performance.
- SP extras
The Hypermotard 1100EVO SP has serrated footpegs for increased boot grip during extreme conditions and a Teflon slider under each peg for protection in extreme lean angles. Ducati include a rubber insert with the bike for riders who prefer to cover the serration for increased comfort.
To enhance control, the tapered alloy handlebars have a 20mm longer bar-riser that effectively changes the riding positioning to enable greater leverage under extreme riding conditions. The risers are finished in black along with the new Marzocchi forks, upper and lower fork clamps, footpeg carriers and pedals, exhaust guard, rear subframe and rear sprocket carrier.
A carbon fibre rear hugger is fitted as standard equipment, enhancing the SP's already extreme image and also providing protection for the Öhlins rear suspension unit. The advanced composite is also used for the fork protectors, timing belt covers, front fender rear section and tail side covers.
- Lighter Trellis frame
The quick and precise handling that the Hypermotard provides is down to the construction and geometry of its famous Trellis frame. Its ability to handle the abundant torque from the L-Twin engine and its rigidity under powerful Brembo braking are just a few reasons why Ducati's chassis department would never want to change it. But it could be made lighter. They realised that almost all of the heavy forged sections of the construction could be completely removed without reducing its strength or its performance, so they applied it to the entire family.
- New controls and instrumentation
The entire Hypermotard family now inherits the electronic advances made in the compact and user-friendly switchgear and instrumentation first created for the Streetfighter.
The slim-line switch bodies house easy-to-use switches and buttons, and feature a unique weapons-like 'trigger catch' that slides down to cover the starter button when the kill-switch is activated. Their minimalist design fits perfectly in the clean and essential lines of the Hypermotard's sporting image.
Looking clean and purposeful, the display provides an extensive amount of data including speed, revs, time, oil temperature, battery voltage, A & B trips, fuel reserve trip and scheduled maintenance, while the warning lights illuminate for neutral, turn signals, high-beam, rev-limit, oil pressure and fuel reserve. In addition, it can list recorded lap times by using the high-beam flash button as a stopwatch. Both the 1100EVO and 1100EVO SP use a white back-lighting while the 796 uses an orange back-lighting.
The instrument display also doubles as a control panel for the activation of the Ducati Data Analyser (DDA) system, which is available as an accessory from Ducati Performance for the 'system-ready' Hypermotard 796 and 1100EVO and supplied as standard equipment on the 1100EVO SP. The DDA-intended USB connection port under all of the Hypermotard seats doubles as a charging point for a handy new battery charger, which is available as an accessory from Ducati Performance.
- Hyper data
Supplied as standard equipment on the 1100EVO SP, the Ducati Data Analyser (DDA), which includes PC software, a USB-ready data retrieval card and instructions, enables owners to review and analyse the performance of the bike and its rider, and make comparisons between various channels of information.
The system records numerous channels of data including throttle opening, vehicle speed, engine rpm, engine temperature, distance travelled, laps and lap times. It also automatically calculates engine rpm and vehicle speed data, enabling it to display gear selection as an additional channel of information. At the end of a ride or track session, up to 4mb of data can be downloaded ready to compare, analyse and get an inside view of the performance of both the rider and the Hypermotard.
- Lighter, more powerful engines
While the chassis department were busy reducing the weight of the frame, the engine department went back to the drawing board for the 796 and started with a clean sheet of paper. Their complete redesign of the crankcases rewarded them with an incredible saving of 1.2kg (2.64lb) compared to the 696 castings, and the new 796 crankshaft with 848-style flywheel further reduced the overall engine weight to an impressive 1.9kg (4.2lb) savings over the 696 power unit. And with 81hp (59.6kW) of smooth and flexible power, the 796 is a very credible package.
The 1100 air-cooled Desmodue Evoluzione engine truly is an 'evolution' - both in power and weight - and is responsible for the model name extension 1100 EVO. Engineers used the same Vacural® technology employed for the lightweight Superbike engines when they vacuum die-cast the Hypermotard 1100 crankcases, a process that achieves a significant weight saving and ensures consistent wall thickness and increased strength. This process - combined with the lightweight crankshaft assembly that uses an 848-style flywheel and use of lighter rare-earth magnets in the alternator - reduced the 1100 power unit's weight by a staggering 5.2kg (11.5lb). Couple those savings with a 5hp boost to 95hp (69.9kW) and it becomes clear why there's all the hype.
Compact and efficient, the Desmodue engine's hyper-lightweight and narrow L-Twin layout, no wider than a single cylinder, ensures that all Hypermotards remain lean and agile. The air-cooled design eliminates the need for water radiators, hoses, reservoirs and pumps, keeping the motorcycle's weight down to a minimum and its lines clean and race-like.
- Lighting and indicators
The headlamp uses a highly compact lighting shape which blends with the single piece nose fairing and front fender moulding, while the rear light employs a specially designed strip of LEDs enhanced by a high diffusion lens shaped into the sleek lines of the tailpiece. The same LEDs are intensified under braking. The front directional indicators also employ the latest in LED technology for illumination, and are ingeniously integrated into the handguards which support the foldable rear view mirrors.
- Footpegs
Rider footpegs on all of the Hypermotard models have removable rubber inserts to expose the serrated metal edge and increase boot grip on the peg during extreme riding. The 1100EVO and 1100EVO SP provide a further minimalist and no-compromise feature by having removable passenger footpegs. This attention to detail enables a clean 'monoposto' look when on the track, while allowing a fast and easy change to 'biposto' for the street.
- Hyper mirrors
Ducati pushed motorcycle design limits to find an innovative solution for the original Hypermotard mirrors and these are now used throughout the family. The challenge of maintaining a clean, racing look around the handlebar area motivated the design of the folding mirror concept which is based on the handguards typically found on off-road bikes. Flipped out for high visibility street mode and easily folded in for a quick change to 'Hypermode', the mirror handguard assemblies also integrate the LED directional indicators for an even cleaner front-end.
- Tailpiece
The high intensity LED rear light assembly is moulded into a unique tailpiece positioned high behind the seat. The supporting structure has been designed so that the under tray of the tailpiece is formed perfectly to offer a sturdy pair of pillion grab-handles. This ingenious solution not only helps to merge the rear light into the Hypermotard styling but also provides a safe grip for the passenger.
